Speed of Solar powered vehicles

EV can travel at 20 km/h at peak sunlight. This is a fast cycling speed. It will only be one quarter sunlight that EV will drop to 5 km/h, at fast walking speed. It may look so slow but at city centres or streets, these are the normal speeds. Are they really possible?

I was inspired by the low electric consumption of a converted Land Rover, who uses up only 1% of battery capacity going off-road across two mountains, whereas a diesel off-road SUV uses up one quarter tank.

The Tesla motor used in the conversion allowed a Tesla Model 3 car to consume 120 Wh/km at an urban cycle that includes highway driving. At slow speeds, only rolling resistance remains so it can drop to 50 Wh/km. A Lightyear One Solar Car averages 80 Wh/km but it uses full hub motors and no gears. It's aerodynamic drag is only slightly better than Model 3 so its slow speed consumption should be around 40 Wh/km, better than a Tesla car, but should not exceed 80 Wh/km. The measurements for a Tesla Roadster indicated a consumption of 50 Wh/km at slow speeds.

An ebike should consume around 8 Wh/km based on my experience and rough calculations using the ebike as fast as 15 km/h. A velomobile or human powered vehicle, with a frontal area of 0.5 sq. m, or 0.7 m X 0.7 m, should consume 10 Wh/km at slow speed. Human powered Velomobile can travel at 80 km/h, using aroud 300 W human power.

A fully electric Velomobile should be heavier than a Velomobile with larger batteries. Total weight should be around 200 kg whereas the total weight of a Velomobile should be less than 150 kg.

Solar area for an electric Velomobile should be around 1 sq m (0.5 m X 2 m), so can generate 200 W power. 200 Wh in one hour. If the consumption is 10 Wh/km, distance travelled in one hour is 200 Wh/ 10 Wh/km, 20 km, or at a speed of 20 km/h.

A Solar Car should be able to generate 1000 W, with a surface area of 5 sq. m. With 50 Wh/km electric consumption, distance travelled in one hour is 1000 Wh / 50 Wh/ km, 20 km.
